PU Sandwich Panel Making Machine
PU Sandwich Panel Making Machine
  • PU Sandwich Panel Making Machine
  • PU Sandwich Panel Making Machine

PU Sandwich Panel Making Machine

Product Description

A special manufacturing machine for roof panel and wall panel made of three
kinds of material, In other words, sandwich panel Including a steel sheet+ PU resin
foam + steel sheet, or steel sheet+ PU resin form + PVC sheet. Sandwich panel
manufactured by this machine has effects of beauty, practicality, heat-insulation,
sound-insulation and fire-resistance.

1.Continual high speed manufacturing equipment.
2.Manufactures very precise PU sandwich panel.
3.It uses PLC for controlling operation and convenient to operate.
4.It has plural computerized automatic cutting systems.
5.It includes a low-pressure PU Injecting machine, measuring accurately, having high stability, giving out little floating volume In the manufacturing environment, and securing health of workers.
Main Technical Datas:
Production type: Continuous and automatic production
Specification of material: thickness 0.3-0.8mm
Width of material: 1200mm Max.
Main power: 40KW
Total power: 100KW
Structure of Roll Forming Machine: upper and lower pressing group, producing with the pu complex mainframe
Structure of complex mainframe: up and down belt positioning, side seal die positioning
Foaing system: Continuous and automatic foaming, foaming capacity can be stepless adjustable.
Foaming thickness: 40-200mm
Speed: 0-10m/min
Way of Controlling: All Siemens PLC Computerized controlling
Total weight: about 30 Ton
Total length; about 95 meters




PU Sandwich Panel Making Machine
Introduction of production line
1.Components
The PU continuous production line composed of un-coiler, Cut off the docking, filming, rib/forming, preheating, foaming, continuous solidify, cutting, stacking and packing etc. with high Automation and stable performance.



Sandwich Panel Machine

Roll Forming area:
There are upper and lower roll Forming Machine and quick change system, it is possible to produce various profiles to meet diversified demands.

PU Sandwich Panel Machinery


Foaming area:
Foaming area composed of High pressure PU foaming machine , casting machine and double crawler etc.PU provided foaming machine with electrical metering mechanism, automatic coil provided system to insure the material mixed according to ratio, spraying equally, the double crawler with accurate temperature control system and safety foaming processing to assure foaming equally and stable.

Sandwich Panel Making Machine

Looking for ideal Sandwich Panel Machine Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the PU Sandwich Panel Machinery are quality guaranteed. We are China Origin Factory of Sandwich Panel Making Machine. If you have any question, please feel free to contact us.
