Electric Cabinet Frame Roll Forming Machine
Electric Cabinet Frame Roll Forming Machine
  • Electric Cabinet Frame Roll Forming Machine
  • Electric Cabinet Frame Roll Forming Machine

Electric Cabinet Frame Roll Forming Machine

    Payment Type: L/C,T/T
    Incoterm: CIF
    Delivery Time: 30 Days

Additional Info

Transportation: Ocean

Product Description

Roll Forming Machine Product Feature:

They are all widely used in steel structure industry, decorating and fitting material industry,

physical distribution and supermarket shelf industry, transportation industry, wiring industry, electrical

equipment industry, elevator industry and various projects using pipe industry.





Electric Cabinet Frame Roll Forming Machine

Technical parameters:

Serial number

Item

Unit

Parameters

Remark

1

Suitable material

Type

cold rolled steel coils(Q235)

strength

MPa

≤350

Thickness

mm

3.0

Coil internal diameter

mm

80

Coil weight

T

3

2

Specification

mm

53--66

3

Line speed

m/min

25

4

Roller material

D2 quenching treatment

5

Roller driven type

External chain transmission

6

Operating system

Windows2000

7

Total motor power

Kw

380V/50HZ

8

Electric control system

PLC automatic control system

9

Dimension(L*W*H)

m




Electric Cabinet Roll Former Excellent Electric Cabinet Roll Forming Machine

Automatic Electric Cabinet Roll Forming Machinery



Why choose Linear Cable Tray Roll Forming Machine?
1. In the design of punching part, we adopt servo feeding technology to make sure that the punching accuracy can reach more or less than 0.15 mm.

1. Rolling stations is 20 steps ,the main machine consists of AC motor,reducer,high precision liner rail, transmission box on left and right, horizontal adjustment system and rolling moulds. The machine base and transmission adopts welding structure , with hardness treatment, the material of roller is 45# steel.

3. The Roll Forming craft is made by the special Germany cold roll forming program COPRA; the craft is also made the FEA analysis and check. The structure of the rollers is combined, so the line speed difference and resisting force of roll forming is small. The sheet is easy to feed. All these assure the accuracy and stable of the roll forming.


Looking for ideal Electric Cabinet Roll Former Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Excellent Electric Cabinet Roll Forming Machine are quality guaranteed. We are China Origin Factory of Automatic Electric Cabinet Roll Forming Machinery. If you have any question, please feel free to contact us.

Product Categories : Electric Industry Roll Forming Line > Electric Cabinet Pillar Roll Forming Machine
