Product Description

Description

Cable Tray Roll Forming Machine consists of decoiler (uncoiler), leveling machine (flattener), servo feeding device, punching system, front cutting device, guiding device, Roll Former, rear straightening device and run-out table. With full and special experience, we can customize cable tray Roll Forming machines or cable tray roll forming production lines according to customers` profile drawings and specifications.

Our cable tray Forming Machine can make the different shape of the cable trays as customer's requests.

Cable Tray Roll Forming Line



Technical parameters:

Serial number

Item

Unit

Parameters

Remark

1

Suitable material

Type

CR,HR Sheet;Galvanized Sheet

strength

MPa

≤350

Thickness

mm

1.6-3.2

Coil internal diameter

mm

500,600

Coil weight

T

5

2

Specification

mm

100-320

3

Line speed

m/min

25

4

Roller material

D2 quenching treatment

5

Roller driven type

External chain transmission

6

Operating system

Windows2000

7

Total motor power

Kw

About 65

8

Electric control system

PLC automatic control system

9

Dimension(L*W*H)

m

30X2X1.7


Cable Tray Production Line

Uncoiling –leveling- Looping-Feeding-punching -Roll forming-Cutting –Discharging

Cable Tray Roll Forming Machine

Looking for ideal Roll Former Line for Cable Tray Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the Cable Tray Roll Forming Machine are quality guaranteed. We are China Origin Factory of Cable Tray Production Line. If you have any question, please feel free to contact us.
